Level regulators for liquids and electronic devices
Flow switches FLOW/MATIC V have been realized at
the purpose to control fluids moved by CIRCULATORS
PUMPS or by CENTRIFUGAL ELECTRIC PUMPS. The
force of working is very reduced, if compared to the
normal constructions which work by means of the
compression or dilation of a metallic casing.
The electric contact is housed externally to the flow
switch and is moved by a magnet located on the flow
valve.
Product:Flow Switch
Installation :Vertical
Hydraulic Connection:1″
Suitable For Size Pipe: 1″
Max Pressure: 10 Bar
Max Liquid Temperature: 85°C
The H-10AR version is equipped of a trimmer
for the regulation of the delay, form 0 to 10 sec., and a test button
The valve high sensibility allows to control also
passages of little quantity of liquids equal to 3 or 0,6 l/
min depending on the model.
The “V” series, produced in FOUR different versions, for
electric contact type and minimum working sensibility,
foresees an threaded input/output joint G1. The
installation can be effected in vertical in series to the
liquid conduction piping, with the possibility of 360°
positioning respect to the flow switch axis.
